Brass Vertical Check Valve
Description Brass Vertical Check Valve Body: Brass Bonnet: Brass Disc: Brass Stem: Brass Rubber: Nitrile Rubber Spring: SS304 Nominal Size: DN15 to DN50 Nominal Pressure: PN16 End Connection: Threaded Threaded Connection: NPT, BSP., BSPT Dimension Unit: mm DN A B C S 15 33.5 47 11 24.5 20 40 54.5 14 31 25 44.5 55 14 38 32 58 63.5 14 46.5 40 65.5 69 17 52 50 75.5 70 17 65
Specs
