Description Additional information Description Mini Ball Valve offers a smooth open and close action to allow or stop the flow of water. The “full flow” design ensures there is minimum head loss and the option of a male/female version eliminates the need for additional fittings. Application The mini ball valve is a quarter-turn type ball valve that used for shut off application in the pipework. The handle can be rotated at 90 degrees to open or close the valve. Besides, They are ideal for use in small, confined spaces, where larger valves are not necessary. They are suitable for residential and light commercial applications in domestic hot and cold water systems, natural or bottled gas, and compressed air systems. Brass Mini Ball Valve Features Regulate and control air, oil also water; Suitable for regular operation, lightweight; Small fluid resistance; Body brass construction; Simple construction; Easy maintenance; Good sealed performance; Freedom from installation direction. General Information Mini ball valves consist of chrome/nickel-plated brass for higher corrosion resistance than regular brass or steel; mini ball valves are the most simple and common kind of valve. Inside the housing, there is a metal ball with a hole through it. By using a valve lever operator, you can rotate the ball thus opening or closing the path for the medium. Industrial miniature ball valves for use as a shut-off valve in water, air, and general fluid service. These valves come in sizes from 1/8 inch to 1/2 inch. Our diverse range of Valves provides you with the ultimate solution to control the flow and pressure within a system or process. They are essential components of a piping system that regulates, control, or directs the flow of a fluid by opening, closing, or partially obstructing fluid flow. Our exclusive valves include a variety of gate, ball, and check valves as well as flow control valves to fulfill your requirements. Moreover, we can supply valves in a wide range of materials. Centre Point Hydraulic maintains the complete inventory of Valves and Quick Release Couplings in the Middle East and Africa, ready to ship to meet your company’s needs. Furthermore, we can provide you with a free consultation and quotation through 971 4 885 6150 or
[email protected]. Data Sheet Additional information Body brass single piece Ball Forged brass Hard chrome plated mirror smooth finish Seat Pure P.T.F.E. Conical arc cut Steam Seals Double “O” rings Handle Nylon End BSP female threads Pressure Rating Fluids 40Kg Temperature Rating Fluids -15° C to 100° C Size 1/4”, 3/8” & 1⁄2”
