Product Description Model No HP Z1 G9 Tower Desktop Processor Intel® Core™ i9-13900 (2.0 GHz P-core base frequency up to 5.2 GHz Max Turbo frequency, 36 MB L3 cache, 24-cores, 32 threads) Chipset Intel® Q670 RAM 32 GB DDR5-4800 SDRAM up to 128 GB DDR5-4800 SDRAM with 4 DIMMs HDD 2TB 3.5 SATA 7200 rpm HDD, 512GB M.2 PCIe NVMe 2280 Value 3X4 SSD Graphics NVIDIA® GeForce RTX™ 3070 GPU 8 GB GDDR6 Operating System FreeDOS Networking Integrated 10/100/1000 NIC Intel® Wi-Fi 6 AX211 (2×2) and Bluetooth® 5.3 wireless card Optical Drive Slim DVD-RW Ports and connectors Front: 1 SuperSpeed USB Type-C® 20Gbps signaling rate (1 charging); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack; Rear: 1 audio-out; 1 HDMI 1.4; 1 power connector; 2 DisplayPort™ 1.4; 3 USB Type-A 480Mbps signaling rate; 3 SuperSpeed USB Type-A 10Gbps signalingrate; 1 RJ-45; Audio Realtek ALC3205 codec, universal audio jack with CTIA and OMTP headset support Expansion slots 1 M.2 2230; 2 PCIe 3 x1; 1 PCIe 3 x16 (wired as x4); 2 M.2 2280; 1 PCIe 4 x16 (1 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage) Drive Bays (2) 3.5” internal storage drive bay (2) Slim optical drive bay (optional, ODD and removable storage) Keyboard & Mouse HP USB Keyboard, HP USB Optical Mouse Security Management HP Power On Authentication, Power-on password (via BIOS), SATA port disablement (via BIOS), Setup password (via BIOS), Support for chassis padlocks and cable lock devices, USB enable/disable (via BIOS), Serial enable/disable (via BIOS), HP Sure Click, Windows Defender, HP Sure Sense, HP Client Security Manager Gen7, HP Sure Start Gen7, HP Sure Run Gen4, HP Sure Recover Gen4, HP Tamper Lock, TPM 2.0 Embedded Security Chip (Common Criteria EAL4 Certified) (FIPS 140-2 Level 2 Certified) Power 550 W 92% efficient, wide-ranging, active PFC Warranty 3 Years Standard Warranty
